28 | Hardware Installation and Maintenance Guide for SG5700 Appliances
Connect this port...
Interconnect port 1 on the E2800 controller
Interconnect port 2 on the E2800 controller
2. Connect management port 1 (P1) on the E2800 controller (the RJ-45 port on the left) to the
management network for SANtricity System Manager, using an Ethernet cable.
Do not use management port 2 (P2) on the E2800 controller (the RJ-45 port on the right). This
port is reserved for technical support.
3. If you plan to use the Admin Network for StorageGRID Webscale, connect management port 1
on the E5700SG controller (the RJ-45 port on the left) to the Admin Network, using an Ethernet
cable.
4. Connect the 10/25-GbE ports on the E5700SG controller to the appropriate network switches,
using optical cables and SFP+ or SFP28 transceivers.
Note: All ports must use the same link speed. Install SFP+ transceivers if you plan to use 10-
GbE link speeds. Install SFP28 transceivers if you plan to use 25-GbE link speeds.
• If you plan to use Fixed port bond mode (default), connect the ports to the StorageGRID
Webscale Grid and Client Networks, as shown in the table.
Port
Port 1
Port 2
Port 3
Port 4
• If you plan to use the Aggregate port bond mode, connect one or more of the network ports to
one or more switches. You should connect at least two of the four ports to avoid having a
single point of failure. If you use more than one switch for a single LACP bond, the switches
must support MLAG or equivalent.
Related concepts
10/25-GbE port connections for the E5700SG controller
Related tasks
Accessing the StorageGRID Webscale Appliance Installer

Connecting power cords and applying power

When you apply power to the appliance, both controllers boot up.
Before you begin
Risk of electrical shock – Before connecting the power cords, make sure that the two
Caution:
power switches on the appliance are off.
Steps
1. Confirm that the two power switches on the appliance are off.
To this port...
Interconnect port 1 on the E5700SG controller
Interconnect port 2 on the E5700SG controller
Connects to...
Client Network (optional)
Grid Network
Client Network (optional)
Grid Network
