20 | Hardware Installation and Maintenance Guide for SG5700 Appliances
Table 2: Information needed to connect the E5700SG controller to the Admin Network
The Admin Network for StorageGRID Webscale is an optional network, used for system
administration and maintenance. The appliance connects to the Admin Network using the 1-GbE
management port 1 on the E5700SG controller.
Information needed
Admin Network enabled
Ethernet switch port you will connect to
management port 1 (P1)
MAC address for management port 1 (printed
on a label near port P1)
DHCP-assigned IP address for management
port 1, if available after power on
If the Admin Network includes a
Note:
DHCP server, the E5700SG controller
displays the DHCP-assigned IP address on its
seven-segment display after it boots up. You
can also determine the DHCP-assigned IP
address by using the MAC address to look up
the assigned IP.
Static IP address you plan to use for the
appliance Storage Node on the Admin Network
Note: If your network does not have a
gateway, specify the same static IPv4 address
for the gateway.
Admin Network subnets (CIDR)
Table 3: Information needed to connect and configure the 10/25-GbE ports on the
E5700SG controller
The four 10/25-GbE ports on the E5700SG controller connect to the StorageGRID Webscale Grid
Network and Client Network.
See "10/25-GbE port connections for the E5700SG controller" for more information about
Note:
the options for these ports.
Information needed
Link speed
If you select 25 GbE, you must install
Note:
SPF28 transceivers. Auto-negotiation is not
supported, so you must also configure the
ports and the connected switches for 25GbE.
Your value
Choose one:
• No
• Yes (default)
• IPv4 address (CIDR):
• Gateway:
• IPv4 address (CIDR):
• Gateway:
Your value
Choose one:
• 10 GbE (default)
• 25 GbE
