NetApp StorageGRID Webscale SG5700 Series Hardware Installation And Maintenance Manual page 31

Display
2 Seven-segment
display
3 Expansion Port
Attention LEDs
4 Host Port Link
Status LEDs
5 Ethernet Link
State LEDs
6 Ethernet
Activity LEDs
General boot-up codes
During boot-up or after a hard reset of the appliance, the following occurs:
1. The seven-segment display on the E5700SG controller shows a general sequence of codes that is
not specific to the controller. The general sequence ends with the codes AA and FF.
2. Boot-up codes that are specific to the E5700SG controller appear.
E5700SG controller boot-up codes
During a normal boot-up of the appliance, the seven-segment display on the E5700SG controller
shows the following codes in the order listed:
Code Indicates
HI The master boot script has started.
PP The system is checking to see if the FPGA needs to be updated.
HP The system is checking to see if the 10/25-GbE controller firmware needs to be
updated.
RB The system is rebooting after applying firmware updates.
FP The hardware subsystem firmware update checks have been completed. Inter-
controller communication services are starting.
HE The system is awaiting connectivity with the E2800 controller and synchronizing with
the SANtricity operating system.
If this boot procedure does not progress past this stage, check the connections
Note:
between the two controllers.
HC The system is checking for existing StorageGRID Webscale installation data.
HO The StorageGRID Webscale Appliance Installer is running.
State
Shows a diagnostic code Seven-segment display sequences enable you
Amber
Green
Off
Green
Off
Green
Off
Blinking Green
Installing the hardware | 31
Description
to understand errors and the operational state
of the appliance.
These LEDs are always amber (no link
established) because the appliance does not
use the expansion ports.
The link is up.
The link is down.
A link is established.
No link is established.
The link between the management port and
the device to which it is connected (such as
an Ethernet switch) is up.
There is no link between the controller and
the connected device.
There is Ethernet activity.
