ProMinent DULCOMARIN 3 Compact Assembly And Operating Instructions Manual page 39

Description Terminal iden‐
tifier
Digital input 6
Digital input 5
Digital input 4
Digital input 3
Digital input 2
Digital input 1
[CAN]
CAN bus 1
Terminals Pin
3 (+V)
XK6 1 (-)
2 (+)
3 (+V)
XK5 1 (-)
2 (+)
3 (+V)
XK4 1 (-)
2 (+)
3 (+V)
XK3 1 (-)
2 (+)
3 (+V)
XK2 1 (-)
2 (+)
3 (+V)
XK1 1 (-)
2 (+)
3 (+V)
XC1 1 (CAN‐
SCHIRM)
2 (CANV+)
3
(CANGND)
4 (CANH)
5 (CANL)
XC3 1 (CAN‐
SCHIRM)
2 (CANV+)
3
(CANGND)
4 (CANH)
Assembly and installation
Signal Function
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
Reference potential External contact input
with 15 V/10 mA
Contact input
power supply
+15 V/10 mA
power supply
CAN shield with CAN 1 local CAN-
connection to PE BUS with external
power supply 20 V /
CAN supply
0.4 A (power-
voltage +20 V/400
restricted) with CAN
mA
shield to PE connector
CAN reference
potential
CAN high
CAN low
CAN shield CAN 1 local CAN-
BUS with external
power supply 20 V /
CAN supply
0.4 A (power-
voltage +20 V/400
restricted) without
mA
CAN shield to PE con‐
nector
CAN reference
potential
CAN high
39
