Installation and configuration manual
DULCOMARIN
3
®
Function extension M-A-P module
EN
A1234
Only valid in conjunction with the complete operating instructions for DULCOMARIN
3
®
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
Part number: 980978
Target group: trained qualified personnel
Version: BA DC 094 11/20 EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DULCOMARIN 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProMinent DULCOMARIN 3

Summary of Contents for ProMinent DULCOMARIN 3

  • Page 1 Installation and configuration manual DULCOMARIN ® Function extension M-A-P module A1234 Only valid in conjunction with the complete operating instructions for DULCOMARIN ® Please carefully read these operating instructions before use. · Do not discard. The operator shall be liable for any damage caused by installation or operating errors. The latest version of the operating instructions are available on our homepage.

  • Page 2: Table Of Contents

    Table of contents Table of contents Introduction................3 Firmware update of the existing CAN modules on the DULCOMARIN ® II..............4 2.1 Performing automatic updates for all modules..... 5 2.2 Performing manual updates.......... 5 2.3 End the software update of all modules......6 2.4 Possible problems with the update.......

  • Page 3: Introduction

    Introduction Introduction This document provides supplementary instructions to the existing documentation for the DULCOMARIN ® 3. The document does not replace the existing documentation. The document supplements the existing documents to provide for the use of existing CAN mod‐ ules in a measuring and control system with several swimming pools.

  • Page 4: Firmware Update Of The Existing Can Modules On The Dulcomarin ® Ii

    DXMaP-module ≧ 3000 DXMaA-module ≧ 3016 DXUa-module ≧ 3089 Downloading the update You can download the latest software version from the ProMinent www.prominent.com . website ‘Service’ ➨ ‘Download Center’ . Enter a search at [Dulcomarin software] The search term is ð...

  • Page 5: Performing Automatic Updates For All Modules

    Firmware update of the existing CAN modules on the DULCOMARIN ® Carrying out the update You need an SD memory card for the update, which contains the Ä ‘Downloading the update’ on page 4 . necessary software, see Keep hold of the SD card after the update. Make sure of the following during the update: The power supply to the DULCOMARIN II is not discon‐...

  • Page 6: End The Software Update Of All Modules

    On a PC, verify that the relevant file is there. You may need to reformat the SD card and copy the files to the SD card again. Use another SD card if you need to. Please contact ProMinent Customer Service on +49 6221/842-0 with any questions...

  • Page 7: Steps After A Software Update

    Firmware update of the existing CAN modules on the DULCOMARIN ® 2.5 Steps after a software update 2.5.1 M-/A-module Once the M-/A-modules have been updated, it is imperative that the configuration of the M-/A-modules is resaved. Press the following keys one after the other to save: [F4 CONF.] [F5 BUS] [F5 CHANGE]...

  • Page 8: Dismantling And Assembly

    Dismantling and assembly Dismantling and assembly Ä Chapter 2 ‘Firm‐ Carry out the actions described in the chapter ware update of the existing CAN modules on the DULCOMARIN ® II’ on page 4 in advance to change the DULCOMARIN ® II to a DULCOMARIN ®...
  • Page 9 Dismantling and assembly DULCOMARIN II DULCOMARIN 3 III. A3187 Fig. 1: Comparison of II and 3. DULCOMARIN II The DULCOMARIN II has several modules (M- / A- or P-module) connected via CAN ® ® bus. DULCOMARIN 3 The DULCOMARIN 3 is connected to several modules (M- / A- or P-module) via CAN ®...

  • Page 10: Disassembling The Dulcomarin ® Ii

    Dismantling and assembly 3.1 Disassembling the DULCOMARIN ® Disassemble the DULCOMARIN II in the following order: ® Disconnect the unit from the power supply. Disconnect the LAN connections, if required. Disconnect the connectors for any modules installed Disconnect the CAN bus. Remove the DULCOMARIN ®...

  • Page 11: Example: Can Bus Cabling

    Dismantling and assembly 3.2.1 Example: CAN bus cabling A3190 Fig. 2: CAN bus cabling A DULCOMARIN ® 3 in the pool caretaker’s office. B Plant room for swimming pool 1 C Plant room for swimming pool 2...

  • Page 12: Commissioning The Dxmax Module On The Dulco- Marin ® 3

    Commissioning the DXMaX module on the DULCOMARIN ® Commissioning the DXMaX module on the DULCOMARIN ® 4.1 Entering the number of swimming pools To start up a multiple pool system, first increase the number of swimming pools on the DULCOMARIN ®...

  • Page 13: Assignment Of Can Modules

    Commissioning the DXMaX module on the DULCOMARIN ® ‘Change’ button can be used to assign other units you have found to the swimming pool and/or remove these units. 4.3 Assignment of CAN modules free free free Select the possible modules for the selected pool.

  • Page 14: Overview Of All Connected Can Modules

    Commissioning the DXMaX module on the DULCOMARIN ® 4.4 Overview of all connected CAN modules Connectivity Assignment of modules BUS details Node-ID Send e-mail enquiry Serial number 20002475121 Software version 3009 Node-ID Send e-mail enquiry Serial number 3017 Software version System overview A3193 Fig.

  • Page 15: Configuring The M-Module (Dxmam, Measurement Module)

    Configuring the M-module (DXMaM, measurement module) Configuring the M-module (DXMaM, measurement module) DXMaM 2021-06-22 14:21:28 START Information Node-ID Serial number 2006036135 Send e-mail enquiry Software version 3016 Identity code DXMAMW0SDE Digital inputs 1 - 3 Measuring inputs Diagnostics Anlagenübersicht When you change or start up the DXMaM module, DXMaM (M-module) press <DXMaM Reload>...

  • Page 16: Measuring Inputs

    Configuring the M-module (DXMaM, measurement module) 5.2 Measuring inputs The M-module has terminals: for a temperature sensor, for an ORP sensor, for pH sensors. A reference potential of the water can also be taken into considera‐ tion. Terminal Value range Remark RTD 1 | 2 (temperature) Not assigned...

  • Page 17: M-Module Diagnostic

    Configuring the M-module (DXMaM, measurement module) 5.3 M-module diagnostic You can immediately view an overview of all the parameters set in the M-module with a diagnostic. The values are updated every 5 seconds. A-module (DXMaA) diagnostics Pool description 1 Functions maximum frequency Pump for pH raising agent strokes/min...

  • Page 18: Reasons For Triggering Eco!Mode

    Configuring the M-module (DXMaM, measurement module) 5.6 Reasons for triggering Eco!Mode Selecting the swimming pool to which the M-module is connected [Eco!Mode] operating mode is active on configures the time when the DULCOMARIN ® If you have selected a swimming pool, swipe left or right ‘Pool settings’...

  • Page 19: Configuring The A-Module (Dxmaa) (Actuator Module)

    Configuring the A-module (DXMaA) (actuator module) Configuring the A-module (DXMaA) (actuator module) A-module (DXMaA) 2021-06-22 14:21:28 Information START Node-ID Send e-mail enquiry Serial number 2006136135 Software version 3016 Identity code DXMAAW2000 Frequency outputs 1 - 3 Digital inputs 1 - 3 mA outputs 1- 3 System overview Diagnostics...

  • Page 20: Ma Outputs 1

    Configuring the A-module (DXMaA) (actuator module) Function of the input Error on the pump (cannot be changed) Function of the input Error on the pump (cannot be changed) Function of the input Error on the pump (cannot be changed) NC / NO Connector type NC / NO normally closed (depending on connector type) Connector type NC / NO...

  • Page 21: Configuring The Ma Outputs

    Configuring the A-module (DXMaA) (actuator module) Actuating variable for ORP raising agent Measured value of mA output, temperature 6.4 Configuring the mA outputs Parameters for mA outputs 2021-06-22 14:21:28 START assigned value at 0/4 mA 0.00 pH assigned value at 20 mA 12.00 pH Range 0 - 20 mA...

  • Page 22: A-Module Diagnostic

    Configuring the A-module (DXMaA) (actuator module) 6.5 A-module diagnostic A-module (DXMaA) diagnostics Pool description 1 Functions maximum frequency Pump for pH raising agent strokes/min Pump for chlorine raising agent strokes/min Pump for flocculant strokes/min Error at the pump Error at the pump Error at the pump Iout1: Measured value of pH mA output...

  • Page 23: Configuring The P-Module (Dxmap) (Power Module)

    Configuring the P-module (DXMaP) (power module) Configuring the P-module (DXMaP) (power module) P-module (DXMaP) 2021-06-22 cNet 14:21:28 Information START Node-ID Send e-mail enquiry Serial number Software version Identity code Relay outputs 1 - 4 Read P-module (DXMaP) settings System overview A3197 Fig.

  • Page 24: Solenoid Valve Relay

    Configuring the P-module (DXMaP) (power module) Terminal Selection Remark minimum 0.0 ... 1250.0 seconds The switching on time is limited to 20 % of the cycle time switching on time The cycle times are to be taken into consideration when actuating solenoid valves (PWM = pulse width modulation).

  • Page 25: Synchronising Settings

    Configuring the P-module (DXMaP) (power module) Cycle Cycle Cycle min. time theoretical Cycle Cycle Cycle min. time actual A0027_GB Fig. 15: Theoretical switching time > (cycle - min. time) and calculated switching time < cycle The DXMaP (P-module) does not switch off for a certain number of cycles until the differences between the cycle and the theoretical switching time exceed the "min.

  • Page 26: Additional Documentation

    Additional documentation Additional documentation Part number of the German Product Description version 982800 Assembly and Operating Instructions for DULCOMARIN ® the Multi-channel Measuring and Control System DULCOMARIN ® , Single and Multi- pool System 986881 Complete instructions for the Multi-channel DULCOMARIN ®...
  • Page 28 ProMinent GmbH Im Schuhmachergewann 5 - 11 69123 Heidelberg, Germany Telephone: +49 6221 842-0 Fax: +49 6221 842-419 Email: info@prominent.com Internet: www.prominent.com 980978, 1, en_GB © 2020...
