Spare parts and accessories
Additional measuring modules
Component
'2x mA input' , with fittings and terminal adhesive label.
Measuring module
'2x pH/ORP/Temp' , with fittings and terminal adhesive
Measuring module
label.
'pH/ORP/Temp // mA input' , with fittings and terminal adhe‐
Measuring module
sive label.
'2x CondC/Temp' , with fittings and terminal adhesive label. 1081809
Measuring module
'2x mA output' , with fittings and terminal adhesive label.
Measuring module
'Serial Sensor' , with fittings and terminal adhesive label.
Measuring module
'CLB' , with fittings and terminal adhesive label.
Measuring module
108
The measuring modules available as accessories can be fitted to
the base modules shown in chapter
layout' on page 46 . For terminal diagrams see Ä Chapter 6.3.4
'Terminal diagram' on page 47 . The measuring modules can
replace or supplement the existing measuring modules. The mod‐
ules are attached, fixed and detected by restarting the controller.
Cabling and commissioning is all as per the measuring modules
available ex-works.
Ä Chapter 6.3.3 'Terminal
Part number
1081806
1081807
1081808
1092565
1092566
1092567
