Output relay, feeding
Relay Function
XR4 relay 4 Output relay 100 ...
230 VAC, feeding
XR5 relay 5 Output relay 100 ...
230 VAC, feeding
XR5 relay 6 Output relay 100 ...
230 VAC, feeding
Tab. 18: Output relay, potential-free
Relay Function
XR1 relay 1 Output relay, poten‐
tial-free (24 VDC or
100 ... 230 VAC)
XR2 relay 2 Output relay, poten‐
tial-free (24 VDC or
100 ... 230 VAC)
XR3 relay 3 Output relay, poten‐
tial-free (24 VDC or
100 ... 230 VAC)
Switching digital output 250 mA
(XA1 ..., XA4)
Tab. 19: Switching; load type: ohmic max. 250 mA; max. 100 Hz
Insulation voltage
Switching voltage (safety low voltage):
Switching current:
Residual current (open):
Switching frequency:
Max. cable length:
Relay type:
Protective circuit Switching power
Varistor on NO and Max. 1100 VA (≤
NC terminal and 5A)
additionally RC cir‐
Starting current
cuit on the NO and
max. 30 A for 0.5
NC terminal
seconds
Varistor on NO and Max. 1100 VA (≤
NC terminal and 5A)
additionally RC cir‐
Starting current
cuit on the NO and
max. 30 A for 0.5
NC terminal
seconds
Varistor on NO and Max. 1100 VA (≤
NC terminal and 5A)
additionally RC cir‐
Starting current
cuit on the NO and
max. 30 A for 0.5
NC terminal
seconds
Protective circuit Switching power
Varistor on the NO Max. 1100 VA (≤ 5A)
and NC terminal
Starting current max.
30 A for 0.5 seconds
Varistor on the NO Max. 1100 VA (≤ 5A)
and NC terminal
Starting current max.
30 A for 0.5 seconds
Varistor on the NO Max. 1100 VA (≤ 5A)
and NC terminal
Starting current max.
30 A for 0.5 seconds
500 V pp max.
30 V AC pp or DC max.
Max. 250 mA
Max. 10 µA
Max. 100 Hz
30 m (EMC standard 61326)
Optomos relay
Technical data
Load type
Ohmic and induc‐
tive on NO terminal
(up to cos phi = 0.4)
Ohmic and induc‐
tive on NO terminal
(up to cos phi = 0.4)
Ohmic and induc‐
tive (up to cos phi =
0.4)
Load type
Ohmic
Ohmic
Ohmic
