CDM-570L Satellite Modem with IP Module

6.16.8 (INFO) MASK (Alarm mask information)

6.16.9 (INFO) REF (Frequency Reference)

6.16.10 (INFO) ID (Circuit ID)

This displays the user-defined Circuit ID string, which is entered via the UTIL, ID
screen. To return to the previous menu, press ENTER.
Remote M&C: 100BaseTx
IP Addr: 255.255.255.255
This shows, in the same format as the CONFIG, Mask sub menu, which alarms
are currently masked. If an alarm is not masked, a blank is displayed in the
relevant screen position.
Mask: FIFO BPV TAIS RAIS
AGC EbNo BUF Ref BUC LNB
This shows the source of the frequency reference for the CDM-570L.
Frequency Reference:
Internal 10 MHz (ENTER)
Circuit ID:
24 CHARACTER TST MESSAGE
(ENTER)
75
Revision 1
MN/CDM570L.IOM
