CDM-570L Satellite Modem with IP Module
OID
CdmipIpRouteRowStatus
Note: The "cdmipIpRouteHdrComp," "cdmipIpRoutePayloadComp" or "cdmipIpRouteDesKey"
OID will only be accessible if the FAST feature has been purchased and activated.
Otherwise, a get GET will return 1 (clear) and a set SET will return an error.
18.6.4
The protocols groups allows user to control networking protocols such as IGMP.
18.6.4.1 IGMP Subgroup
This subgroups controls the IGMP, Internet Group Management Protocol, which is the
standard for IP multicasting in the Internet.
18.6.5
This group controls a redundant pair of modems.

Protocols Group

Redundancy Group

Description
Used in GET operations to tell if the route
table entry is active. Used in SET operations
to tell if a new route table entry is to be created
or an existing route table entry is to be
deleted.
It returns 1 (active) to indicate that the route
entry is available for use by the managed
device. The values of 2 (notInService) and 3
(notReady) are not supported.
When a new route entry is created, this OID
must be set to 4 (createAndGo). The value of
5 (createAndWait) is not supported.
If an existing row is to be deleted this OID
must be set to 6 (destroy), which indicates that
the user's desire to delete the route from the
route table.
The "cdmipIpRouteRowStatus" can return:
1 Active
The "cdmipIpRouteRowStatus" can be set to
the following for row create/delete:
4 Create And Go
6 Destroy
