CDM-570L Satellite Modem with IP Module

6.12 (CONFIG) MASK

Alarm Mask: Transmit
Receive Ref BUC LNB (◄ ►)
Select Transmit, Receive or Reference, using the ◄ ► arrow keys, then press
ENTER.
If Transmit is selected the following sub-menu will be displayed:
Tx Alarm Mask: Tx-FIFO
G.703-BPV Tx-AIS(◄ ►,ENT)
Tx-FIFO Alarm:
Masked (◄ ►,ENT)
Active
Select Tx-FIFO, G.703-BPV or Tx-AIS, using the ◄ ► arrow keys, then press
ENTER. For each of the choices a sub-menu similar to the one shown below
will be displayed:
Select Active or Masked, using the ◄ ► arrow keys, then press ENTER
If the user selects Active, then a Transmit Traffic fault will be generated
whenever the transmitter sees that the transmit FIFO has slipped.
Similarly, the user can mask a G.703 BPV or Transmit AIS alarm.
If the user selects Masked, no alarm will be generated.
If Receive is selected the following sub-menu will be displayed:
Rx Alarm Mask: AGC Eb/No
Rx-AIS Buffer
Select AGC, Eb/No, Rx-AIS or Buffer, using the ◄ ► arrow keys, then press
ENTER. For each of the choices a sub-menu similar to the one shown below
will be displayed:
AGC Alarm:
Active
Select Active or Masked, using the ◄ ► arrow keys, then press
ENTER.
(◄ ►,ENT)
Masked (◄ ►,ENT)
