Select On or Off , using the ◄ ► arrow keys, then press
ENTER.
(CONFIG, ODU, BUC) DC-POWER
If DC-Power is selected, the following sub-menu is displayed:
BUC DC Power:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC) 10MHz
If 10MHz is selected, the following sub-menu is displayed:
BUC 10MHz Reference:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC) ALARM
If Alarm is selected, the following sub-menu is displayed:
Set BUC Current Alarm:
Upper Lower
Select Upper or Lower , using the ◄ ► arrow keys, then press
ENTER.
If Upper is selected, the following sub-menu is displayed:
BUC Current Alarm Upper
Limit:1200mA (◄ ►,▲ ▼,ENT)
Edit BUC Current Alarm Upper limit. This is accomplished by
selecting the digit to be edited, using the ◄ ► arrow keys. The
value of the digit is then changed using the ▲ ▼ arrow keys.
58
(◄ ►,ENTER)
(◄ ►,ENTER)
(◄ ►,ENTER)
