CDM-570L Satellite Modem with IP Module
1
1E-1
1E-2
1E-3
1E-4
1E-5
1E-6
1E-7
1E-8
1E-9
1
BER

Figure 13. 8-PSK/TCM Rate 2/3 with concatenated RS Outer Code

2 3 4 5
Uncoded BPSK/QPSK
Typical
Performance
Specification limit
Rate 2/3 Coding and
220,200 RS Outer Code
2 3 4 5
6 7 8 9
8-PSK/TCM Rate 2/3
Decoding, with 220,
200 RS Outer Code
Specification
limit, Rate 2/3
Coding
6 7 8 9
96
Revision 1

MN/CDM570L.IOM

Eb/No in dB
10 11 12
10 11 12
