CDM-570L Satellite Modem with IP Module
Write Community
Trap Community

18.4 SNMP Traps

The CDM-570L has the ability to send out SNMP traps when certain events occur in the
modem. For example, when the CDM-570L IP Controller boots it sends out a coldstart
trap and three linkup traps, one for each interface that is brought up. The CDM-570L also
sends out traps when an alarm or a fault occurs in the modem. These include unit faults,
TX faults, and RX faults. A trap is sent both when a fault occurs and is cleared.
The CDM-570L supports both SNMPv1 traps and SNMPv2 notifications. Which style of
traps the CDM-570L sends can be configured by the user using the
cdmipSnmpTrapVersion OID.
The following are the MIB2 v1traps/v2 notifications that the CDM-570L supports.
CDM-570L IP Controller MIB2 SNMPv1 traps:
CDM-570L MIB2 SNMPv2 notifications:
The following tables are the Alarms and Faults v1 traps / v2 notifications that the CDM-
570L supports.
CDM-570L Alarms and Faults SNMPv1 traps:
CDM-570L Alarms and Faults SNMPv2 notifications:
cdm570LunitAlarm
default = private
default = public
Cold Start
Link Up
Authentication Failure
Cold Start
Link Up
Authentication Failure
Cdm570LUnitAlarm
Cdm570LTxTrafficAlarm
Cdm570LRxTrafficAlarm
cdm570LODUAlarm
261
1
4
5
1.3.6.1.6.3.1.1.5.1
1.3.6.1.6.3.1.1.5.4
1.3.6.1.6.3.1.1.5.5
6247241
6247242
6247243
6247244
1.3.6.1.4.1.6247.24.2.0.1
Revision 1
MN/CDM570L.IOM
