CDM-570L Satellite Modem with IP Module

6.8.9 (CONFIG, RX) INVERSION FUNCTIONS

Rx Inversion functions:
Spectrum
Select Spectrum or Data, using the ◄ ► arrow keys, then press ENTER.
If Spectrum is selected, the following sub-menu will be displayed:
If Data is selected, the following sub-menu will be displayed:
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.

6.8.10 (CONFIG, RX) Eb/No

Eb/No Alarm Point:
02.0 dB
Edit the Eb/No alarm point. This is accomplished by selecting the digit to be edited, using
the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys.
The user should then press ENTER.
The range of values is from 0.1 to 16.0 dB. The user may select a value here, and if the
Eb/No falls below this value, a receive traffic fault will be generated.

6.9 (CONFIG) FRAME (Framing Mode)

Data (◄ ►,ENT)
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
Rx Spectrum:
(◄ ►,ENTER)
Inverted
Rx Data Sense:
(◄ ►,ENTER)
Inverted
(◄ ►,▲ ▼,ENTER)
Framing Mode:
EDMAC EDMAC-2
Normal
Normal
Unframed
(◄ ►,ENT)
