CDM-570L Satellite Modem with IP Module
fw10874-3-
.mib
CDMIP
Controller
MIB file
fw10874-4-
.mib
CDM-570L
MIB file
fw10874-5-
.mib
CDM-570L
Traps
MIB file
These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring
System server.
Note: The CDM-570L SNMP agent supports both SNMPv1 and v2c. The CDM-570L Traps
file only needs to be compiled if SNMPv1 traps are to be used.
Any changes made to the IP Controller will be lost if the IP Controller is reset or loses
IMPORTANT
All base modem parameters configured via the IP Controller (i.e. - TX Frequency, data

18.3 SNMP Community Strings

The CDM-IP570L uses community strings as a password scheme that provides
authentication before gaining access to the CDM-IP570L agent's MIBs.
In SNMP v1/v2c, the community string is sent unencrypted in the SNMP packets.
Caution must be taken by the network administrator to ensure that SNMP packets travel
only over a secure and private network if security is a concern. A packet sniffer can
easily obtain the community string by viewing the SNMP traffic on the network.
The community string is entered into the MIB Browser or Network Node Management
software and is used to authenticate users and determine access privileges to the SNMP
agent.
The user defines three Community Strings for SNMP access:
Read Community
Module: ComtechEFData
CDMIP Controller MIB file consists of all of the OID's for management of the IP
Controller functions.
CDM-570L MIB file consists of all of the OID's for management of the CDM-570L
modem functions
CDM-570L Trap MIB file is provided for SNMPv1 traps
power unless the changes are saved to permanent storage. This applies to all of
the Controller IP parameters. The Controller parameters can be saved by a SET of
the cdmipSaveConfiguration OID within the cdmipController MIB.
rate, etc.) and the Ethernet Port Address/Mask will be automatically stored in the
CDM-570L base modem non-volatile RAM and will be retained if there is a power
loss.
default = public
