CDM-570L Satellite Modem with IP Module
Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
Qualifier)
Equipment ID
N/A
11 bytes
Description of Arguments
to Query
Query only.
Unit returns information concerning the equipment identification,
and the option field, in the form abbbcdefghi;
where:
a = Turbo option: 0 = None, 1 = Turbo, 2 = TPC/LDPC
bbb = defines the modem model number (571 in this case)
c = RS Codec Option: 0 = None, 1 = Installed
d = Data Rate Option: 0 = Base (512 kbps), 1 = up to 2048 kbps,
2 = up to 5000 kbps
e = Higher-order modulation: 0= None, 1 = 8-PSK/8-QAM,
2 = 16QAM, 3 = 8-PSK/8-QAM and 16QAM
f = IP Module: 0 = None, 1 = Installed
g = BUC option: 0 = None, 1 = 100 Watt, 2 = 150 Watt
h = Spare – for future use
i = Spare – for future use
Example: EID=157101311xx means Turbo, CDM-570L, No RS
codec, up to 2048bps, 8-PSK/8-QAM and 16-QAM, IP Module
installed, 100 Watt BUC supply installed
Response to
Command
N/A
150
Revision 1

MN/CDM570L.IOM

Query
(Instruction
Response to Query
Code and
Qualifier)
EID?
EID= abbbcdefghi
(see description of
arguments)
571 is the CDM-570L
