Mn/Cdm570L.iom - Comtech EF Data CDM-570L Installation And Operation Manual

CDM-570L Satellite Modem with IP Module
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
BUC LO BLO= 6 bytes
Frequency
BUC Output N/A 4 bytes
Power Level
BUC N/A 3 bytes
Temperature
BUC PLL N/A 1 byte, value
Alarm of 0 or 1
Description of Arguments
to Query
Command or Query.
BUC transmit LO frequency information in the form: xxxxxs,
where:
xxxxx is the LO frequency, in the range of 3000 to 65000 MHz
All 0's (000000) disables the feature.
s is the sign for the mix (+ or - character)
Terminal Frequency = BUC LO ± TFQ
Example: BLO = 12000+ (BUC LO is 12 GHz, low-side mix)
Query only.
BUC output power level in the form xx.x, where xx.x is the value
in Watts.
Example: BOL=08.3 (BUC reports output power is 8.3 Watts)
Returns 00.0 when FSK and BUC power are not enabled.
Query only.
Indicates BUC temperature, in the form: sxx, where:
s = sign (+ or - character)
xx = value
If not available, response is –99
Example: BUT=-13 (BUC temperature is -13 degrees C)
Note: This query is only valid when the FSK and BUC power are
turned On.
Query only.
BUC PLL lock state, where:
0=Unlocked
1=Locked
Example: BPA=1 (BUC PLL is locked)
If not available, response is 9
Note: This command is only valid when the FSK and BUC power
are turned On.
Response to
Command
BLO=
BLO?
BLO*
BLO#
N/A
N/A
N/A
154
Revision 1

MN/CDM570L.IOM

Query
(Instruction
Response to Query
Code and
Qualifier)
BLO? BLO=xxxxxs
(see description of
arguments)
BOL? BOL=xx.x
(see description of
arguments)
BUT? BUT=sxx
(see description of
arguments)
BPA? BPA=x
(see description of
arguments)
