CDM-570L Satellite Modem with IP Module

6.16.3 (INFO) RX (Receive information)

6.16.4 (INFO) BUFF (Buffer information)

This displays if the buffer is enabled or disabled, shows the exact clocking mode
(Tx=Rx, or Tx<> Rx), and the buffer size. Pressing ENTER takes the user back to the
previous menu.

6.16.5 (INFO) FRAME (Framing and EDMAC information)

Rx:1140.000 5000.000 TUR
8P 0.95 D BUF +/-32k
The information displayed here is as follows:
Top line:
Receive Frequency and Data Rate (NOTE: Due to space limitations, the
resolution of displayed frequency is limited to 1 kHz, and data rate to 10Hz,)
FEC Decoder type (VIT = Viterbi, VRS=Viterbi + Reed-Solomon,
TCM = Trellis Coded + Reed-Solomon, TUR = Turbo, UNC = uncoded)
Bottom line:
Demodulation type (Q = QPSK, OQ= OQPSK, B = BPSK, 8P = 8-PSK,
Code Rate (Unc = Uncoded, 2144 = 21/44, then 5/16, 1/2, 2/3, 3/4, 7/8, 0.95)
Descrambler state (D = Descrambler on, N = Descrambler off)
Clocking Mode (SAT = buffer disabled, BUF = buffer enabled)
Demod Sweep Acquisition range
RSI state (I = Receive Spectral Inversion on, N = off)
Buffer: Enabled
Size:+/-04096 bits (ENT)
Examples:
Framing: Disabled
(ENTER or CLEAR)
Framing:AUPC-Only,EDMAC2
(ENTER or CLEAR)
I
8Q = 8QAM, 16=16-QAM).
(Tx=Rx)
73
Revision 1
MN/CDM570L.IOM
