CDM-570L Satellite Modem with IP Module
Reporting Comments or Suggestions Concerning this Manual
Comments and suggestions regarding the content and design of this manual will be
appreciated. To submit comments, please contact the Comtech EF Data Technical
Publications Department: techpub@comtechefdata.com.

Electrical Safety

The CDM-570L Modem has been shown to comply with the following safety standard:
The equipment is rated for operation over the range 100 - 240 volts AC. It has a
maximum power consumption of 250 Watts (when equipped with a 150W BUC power
supply), and draws a maximum of 2.5 Amps.
IMPORTANT
Fuses
The CDM-570L is fitted with two fuses - one each for line and neutral connections.
These are contained within the body of the IEC power inlet connector, behind a small
plastic flap.
•
For 230 volt AC operation, use T2.5A, 20mm fuses.
•
For 115 volt AC operation, use T5.0A fuses, 20mm fuses.
FOR CONTINUED OPERATOR SAFETY, ALWAYS REPLACE THE FUSES
WITH THE CORRECT TYPE AND RATING.
Environmental
The CDM-570L must not be operated in an environment where the unit is exposed to
extremes of temperature outside the ambient range 0 to 50°C, precipitation, condensation,
or humid atmospheres above 95% RH, altitudes (non-pressurized) greater than 2000
meters, excessive dust or vibration, flammable gases, corrosive or explosive atmospheres.
Operation in vehicles or other transportable installations that are equipped to provide a
stable environment is permitted. If such vehicles do not provide a stable environment,
safety of the equipment to EN60950 may not be guaranteed.
•
EN 60950: Safety of Information Technology Equipment, including
electrical business machines
The user should observe the following instructions:
