CDM-570L Satellite Modem with IP Module
18.5.2.5 The IP Address Table
This table is implemented per RFC1213.
18.5.2.6 The Route Table
Because the CDM-570L does not use a standard route table, the functionality usually
provided by the ipRouteTable is implemented in the IP-Controller's private MIB. Please
use the IP Controller private MIB's route table to add, change, or delete routes.
18.5.2.7 The Net to Media Translation table
This table is implemented per RFC1213.
18.5.2.8 Additional IP Objects
The ipRoutingDiscards OID is the number of routing entries which were chosen to be
discarded even though they are valid.
18.5.3
This group contains the Internet Control Message Protocol (ICMP) input and output
statistics. ICMP messages are used for out-of-band messages related to network
operation. This group is implemented per RFC1213.
18.5.4
This group contains statistics and control parameters for the TCP protocol. This group
contains a table describing the current TCP connections.
Note: The instances of object types that represent information about a particular TCP connection
are transient; they persist only as long as the connection in question.
Table ?. TCP Group OIDs

ICMP Group

TCP Group

265
Revision 1
MN/CDM570L.IOM
