16.2.8.2 Receive Modem Configuration Page
The Receive Modem Configuration page is activated from the Modem Parameters page .
The Receive Modem Configuration Page contains the following options/fields:
Note: Turbo FEC selections only diplayed if Turbo card is installed
Menu Options/Fields
Receive Frequency
Receive Data Rate
Decoder Type
Entry Description
Q Valid ranges are from 950 to 1950 MHz.
D Valid ranges are from 2.4 to 5000 kbps.
T 1 - NONE
2 - VIT
3 - TURBO
4 – VIT+RS
5 – TCM-RS
6 – LDPC
