CDM-570L Satellite Modem with IP Module
(CONFIG, REM, INTFC, ADDR) RS485 BUS ADDRESS
(CONFIG, REM, BAUD RATE)

6.5.2 (CONFIG, REMOTE) ETHERNET

If Ethernet is selected:
Ether IP Address/Range:
192.168.001.001/24 ◄ ►,▲ ▼
Edit the IP Address and Range for the Ethernet M&C port for this unit. This is
accomplished by selecting the digit to be edited, using the ◄ ► arrow keys. The value
of the digit is then changed using the ▲ ▼ arrow keys. The user should then press
ENTER.
However, if either RS485 mode is selected, the user will be further prompted:
RS485 Bus Address: 0245
(◄ ►,▲ ▼,ENTER)
Edit the RS485 bus address of this unit. This is accomplished by selecting the
digit to be edited, using the ◄ ► arrow keys. The value of the digit is then
changed using the ▲▼arrow keys. The user should then press ENTER. The
valid range of addresses is from 1 to 9999.
If the user selects Baud Rate, the user is presented with the following menu:
Local M&C Bus Baud Rate:
19200 Baud
Edit the baud rate of the remote control bus, connected locally to the M&C
computer. The value is changed using the ▲ ▼arrow keys. The user should then
press ENTER. Values of 2400, 4800, 9600,19200, 38400 and 57600 baud are
possible.
Note that the asynchronous character format is FIXED at 8 data bits, 1 stop bit,
no parity (8-N-1).
(▲ ▼,ENTER)
32
Revision 1
MN/CDM570L.IOM
