CDM-570L Satellite Modem with IP Module
Menu Options/Fields
Encoder Rate
Modulation Type
Spectrum
Scrambler
Tx Output Power
Carrier
Save Parameters
Exit
Entry Description
1 – 5/16
R
2 – 21/44
3 – 1/2
4 – 2/3
5 – 3/4
6 – 7/8
7 – 0.95
9 – 1/1
M Sets transmit modulation type
1 -- BPSK
2 -- QPSK
3 -- OQPSK
4 -- 8PSK
5 -- 16-QAM
U 1 - NRM
2 - INV
B 1 - OFF
2 - ON
P Valid ranges are from 0.0 to 40.0 dBm
(minus sign assumed)
C 1 - OFF
2 - ON
S This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
X This option allows a user to exit the current menu and
return to its parent menu.
