Mn/Cdm570L.iom - Comtech EF Data CDM-570L Installation And Operation Manual

CDM-570L Satellite Modem with IP Module
Menu Options/Fields
Entry001 - 008
Add IP to MAC ARP entry
Delete ARP Entry
Display ARP Tbl
Flush ARP Table
Base
Save Parameters
Exit
Entry
1 - 8 The user can define up to 256 static ARP definitions on
IP M
the odule. This table allows the user to
operate/view up to 8 of these definitions. An ARP
definition is defined as:
1. Unicast IP Address
This IP Address is used as a lookup into the ARP table
IP M
when the
Address.
Restrictions:
IP Address must be on the same subnet as the
Ethernet Interface.
IP Address must be a valid Unicast address (Not
Multicast, broadcast, etc.)
2. MAC Address
The MAC Address defines the hardware destination
MAC Address that is used when an Ethernet packet
is destined for an IP machine from the
M Adds an IP to MAC ARP entry.
Allows the user to delete a Static ARP entry. Queries
D
the user for the IP address of the ARP entry to delete.
A Displays the entire IP to MAC ARP table. Includes the
Static as well as dynamic ARP entries. Displays blocks
of 10 ARP entries. Hit 'Enter' key to display next 10
entries or 'Escape' to return to ARP Table Utilities
page.
F This option allows the entire ARP table to be removed.
This is equivalent to performing the standard UNIX
command "arp –d" on each address reported in an "arp
–a" command. The command only flushes the dynamic
ARP entries. The static ARP entries will not be
removed.
B The ARP Table menu allows the user to view up to 8
different ARP definitions per screen. To allow editing
on any of the 256 entries that can be defined, the user
can select a base address to control which 8 ARP
entries are displayed. For example, if the user wants to
edit static ARP Entries 32-40, then a Base value of 32
should be defined.
S This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
X This option allows a user to exit the current menu and
return to its parent menu.
219
Description
odule needs to resolve a MAC or HDLC
Revision 1

MN/CDM570L.IOM

IP M
odule.
