CDM-570L Satellite Modem with IP Module
The user should then press ENTER. The range of current is 500
to 4000 mA.
If Lower is selected, the following sub-menu is displayed:
BUC Current Alarm Lower
Limit:1200mA (◄ ►,▲ ▼,ENT)
Edit BUC Current Alarm Lower limit. This is accomplished by
selecting the digit to be edited, using ◄ ► arrow keys. The
value of the digit is then changed using ▲ ▼ arrow keys. The
user should then press ENTER. The range of current is 0 to
3000 mA.
(CONFIG, ODU, BUC) LO
If LO is selected, the following sub-menu is displayed:
BUC LO Frequency:
12000 MHz (◄ ►,▲ ▼,ENTER)
Edit the value of the BUC LO frequency. This is accomplished by
selecting the digit to be edited, using the ◄ ► arrow keys. The value of
the digit is then changed using the ▲ ▼ arrow keys. The user should
then press ENTER. The valid range is from 3000 to 65000 MHz.
Note this value is used to display the RF frequency of the modem/BUC
combination. If a value of 00000 is entered here (the default), then no RF
frequency will be displayed on the CONFIG, Tx, Tx Freq menu.
