Specifications

6.3.7 Digital Output

Number of digital outputs
Terminals 27 and 29
Terminal number
Voltage level at digital output
Maximum output current (sink and source)
Terminals 42 and 45
Terminal number
Voltage level at digital output
Maximum output current at digital output
Maximum load at digital output
1) Terminals 27 and 29 can also be programmed as input.
2) Terminals 42 and 45 can also be programmed as analog output.
The digital outputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.

6.3.8 Control Card, RS485 Serial Communication

Terminal number
Terminal number

6.3.9 Control Card, 24 V DC Output

Terminal number
Maximum load

6.3.10 Relay Output

Programmable relay output
Relay 01 and 02
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Minimum terminal load on 01–03 (NC), 01–02 (NO)
Environment according to EN 60664-1
1) IEC 60947 parts 4 and 5.

6.3.11 Control Card, 10 V DC Output

Terminal number
Output voltage
Maximum load
MG18A802
Quick Guide
1) on 01–02/04–05 (NO) (resistive load)
on 01–02/04–05 (NO) (inductive load @ cosφ 0.4)
1)
1)
on 01–02/04–05 (NO) (resistive load)
1)
on 01–02/04–05 (NO) (inductive load)
1)
on 01–03/04–06 (NC) (resistive load)
on 01–03/04–06 (NC) (inductive load @ cosφ 0.4)
1)
1) on 01–03/04–06 (NC) (resistive load)
Danfoss A/S © 05/2016 All rights reserved.
68 (P, TX+, RX+), 69 (N, TX-, RX-)
61 common for terminals 68 and 69
01–03 (NC), 01–02 (NO), 04–06 (NC), 04–05 (NO)
24 V DC 10 mA, 24 V AC 20 mA
Overvoltage category III/pollution degree 2
4
1)
27, 29
0–24 V
40 mA
2)
42, 45
17 V
20 mA
1 kΩ
6 6
12
80 mA
2
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
24 V DC, 0.1 A
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
50
10.5 V ±0.5 V
25 mA
51
