Installation
Enclosure size I3
1 RS485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.14 Enclosure Size I3
IP54, 380–480 V, 5.5–7.5 kW (7.5–10 hp)
MG18A802
Quick Guide
Enclosure size I4
1 RS485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.15 Enclosure Size I4
IP54, 380–480 V, 0.75–4.0 kW (1–5 hp)
Illustration 3.16 IP54 Enclosure Sizes I2, I3, I4
Danfoss A/S © 05/2016 All rights reserved.
3
