Technical specifications
Interface and hardware specifications
The following table provides the interface and hardware specifications for the device.
Specification
Dimensions
Weight
Operating temperature
Antenna connector
Digital I/O
ADC
Cellular chipset
Form factor
SIM size
Cellular RF characteristics
The following table provides the RF characteristics for the device.
Specification
Transmit power
Receive sensitivity
Bluetooth RF characteristics
The following table provides the Bluetooth RF characteristics for the device.
Specification
Transmit power
Receive sensitivity, 1 Mb/s data rate
Receive sensitivity, 2 Mb/s data rate
Operating frequency band
Cellular Networking specifications
The following table provides the networking and carrier specifications for the device.
Digi XBee3 Cellular LTE-M Global Smart Modem User Guide
Interface and hardware specifications
Value
24.38 mm x 32.94 mm (0.960 x 1.297 in)
5 g (0.18 oz)
-40 to +85 °C
Cellular: U.FL
Bluetooth: U.FL
13 I/O lines
4 10-bit analog inputs
u-blox SARA-R410M
Digi XBee 20-pin through-hole
4FF Nano
Value
Up to 23 dBm, Power Class 3
-105 dBm
Value
Up to 8 dBm
-94 dBm
-90 dBm
ISM 2.4 - 2.4835 GHz
58
