Getting started with the XBee Smart Modem Development Kit

Configure the device using XCTU

XBee Configuration and Test Utility (XCTU) is a multi-platform program that enables users to interact
with Digi radio frequency (RF) devices through a graphical interface. The application includes built-in
tools that make it easy to set up, configure, and test Digi RF devices.
XCTU does not work directly over an SPI interface.
For instructions on downloading and using XCTU, see
Note If you are on a macOS computer and encounter problems installing XCTU, see
Java error.

Add a device

These instructions show you how to add the XBee Smart Modem to XCTU. If XCTU does not find your
serial port, see Cannot find the serial port for the
1. Launch XCTU
2. Click the Discover radio modules button
3. In the Discover radio devices dialog, select the serial ports where you want to look for XBee
modules, and click Next.
4. In the Set port parameters window, maintain the default values and click Finish.
5. As XCTU locates radio modules, they appear in the Discovering radio modules dialog box.
If your module could not be found, XCTU displays the Could not find any radio module dialog
providing possible reasons why the module could not be added.
Digi XBee3 Cellular LTE-M Global Smart Modem User Guide
device.
.

Configure the device using XCTU

the XCTU User Guide.
.
