Debugging - Digi XB3-C-A2-UT series User Manual

Getting started with the XBee Smart Modem Development Kit
9. Click the Consoles working mode button
device. For instructions on using the Console, see the
10. Click the Open button
11. Click in the left pane of the Console log, then type in the Console to talk to the echo server.
The following screenshot provides an example of this chat.

Debugging

If you experience problems with the settings in this example, you can load the default settings in
XCTU:
1. On the Configuration toolbar, click the Default button
established by the firmware, and click Yes to confirm.
2. Factory settings are loaded but not written to the device. To write them, click the Write button
on the toolbar.
Digi XBee3 Cellular LTE-M Global Smart Modem User Guide
on the toolbar to open a serial console to the
to open a serial connection to the device.
Connect to the echo server
AT console topic in the XCTU User Guide.
to load the default values
23
