11.5.1 Bar dimensions S14
3PH From 300 to 400A
3PH From 450 to 500A
A
Current
300A (S14) 71mm 60mm 45mm 57mm 30mm
350A (S14) 71mm 60mm 45mm 57mm 30mm
400A (S14) 71mm 60mm 45mm 57mm 30mm
450A (S14) 54mm 76mm 21mm 37mm 66mm 35mm 390mm 165mm M10
500A (S14) 54mm 76mm 21mm 37mm 66mm 35mm 390mm 165mm M10
Neut-Eng-REVO-C-3PH-300-800A-Thyristors-Units
B
C
D
REVO C
E
F
G
-
350mm 174mm M10
-
350mm 174mm M10
-
350mm 174mm M10
24
User's Manual
