Intel R2000WF Configuration Manual page 125

Intel Product Code
iPC – A2UHANDLKIT
iPC – FXX25HSCAR3
iPC – FXX35HSCAR2
Intel® Server S2600WF Product Family Configuration Guide and Spares/Accessories List
Order Information
MM# – 936038
UPC – 00735858288866
EAN – 5032037068147
MOQ – 1
MM# – 958244
UPC – 00735858345668
EAN – 5032037106153
MOQ – 1
MM# – 958245
UPC – 00735858345675
EAN – 5032037106160
MOQ – 1
Product Description
1U / 2U Rack Handle Kit
This kit includes 3 different rack handles, including:
- (1) Set of 2U storage rack handles with control panel and USB
support (R2312WFxxxx & R2224WFxxxx)
- (1) Set of 2U non –storage rack handles (R2208WFxxxx &
R2208WFxxxx + 8 Drive Accessory Kit)
- (1) Set of 1U rack handles (R1304WFxxxx & R1208WFxxxx
This kit includes replacement chassis handles for ALL product family
1U and 2U systems. In addition, this kit must be purchased for 2U
building block configurations consisting of 24x2.5" drives (3 drive
bay modules) or when upgrading a R2208WF or R2208WF + 8 Drive
Accessory Kit system to a 24 drive R2224WF system, where the
standard chassis rack handles must be replaced with a pair of
Storage Rack Handles that include the system front panel and front
USB 2.0 port.
See the appropriate Intel Server System Product Family System
Integration and Service Guide for complete system integration,
upgrade, and part replacement instructions.
Note: The 2U storage rack handles are not supported on
R2312WFTF systems.
2.5" Tool Less Hot Swap Drive Carrier
Spare 2.5" Tool less drive hot swap carrier
3.5" Tool Less Hot Swap Drive Carrier
Spare 3.5" Tool less drive hot swap drive carrier
Includes mounting screws for mounting 2.5" SSDs.
Product Type
• 2U – 24 2.5" Drive Upgrade
Kit
• 1U / 2U Spares Kit
• 1U / 2U Spare FRU
• 1U / 2U Spare FRU
125
