Intel® Server System R2000SC Family
Quick Installation User's Guide
Thank you for buying an Intel® Server System. The following information will help you
assemble your Intel ® Server System and install components.
If you are not familiar with ESD [Electrostatic Discharge] procedures used during
system integration, see the complete ESD procedures described in your Service Guide.
This guide and other supporting documents are located on the web at:
http://www.intel.com/support.
G71872-002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2000SC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intel R2000SC Series

  • Page 1 Intel® Server System R2000SC Family Quick Installation User's Guide Thank you for buying an Intel® Server System. The following information will help you assemble your Intel ® Server System and install components. If you are not familiar with ESD [Electrostatic Discharge] procedures used during system integration, see the complete ESD procedures described in your Service Guide.
  • Page 2 (This page is intentionally left blank.)
  • Page 3: Table Of Contents

    Install the Air Duct ......................6 Install Add-in Card ....................... 7 Install Rack Handles ......................7 Install Intel® RAID C600 Upgrade Key (optional) ..........7 Install Intel® Remote Management Module 4 (optional) ........ 7 Install Intel® RAID Smart Battery (optional) ............7 Install Second Power Supply Module (optional) ..........
  • Page 4 Intel is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the property of others. Copyright © 2012, Intel Corporation. All rights reserved.
  • Page 5: System Overview

    * R2308SC2SHDR as shown Useful Information: • The system must be configured with two CPUs to enable PCIe slot 5 (blue color). • The mini-SAS connector labeled SCU_1 requires an 8-port SATA/SAS Intel RAID C600 Upgrade Key to be functional. ®...
  • Page 6: General Installation Process

    General Installation Process The installation instructions in this section are for common components of Intel® Server System R2000SC family. Minimum Hardware Requirements Preparing the System To avoid integration difficulties and possible board damage, your system must Observe normal ESD (Electrostatic Discharge) meet the following minimum requirements: procedures.
  • Page 7: Install The Processor(S)

    General Installation Process Install the Processor(s) A. Open the Socket Lever B. Open the Load Plate C. Remove the Processor Push the lever handle down and away Push the rear tab with your finger tip to bring CAUTION: from the socket to release it. Protective Cover the front end of the load plate up slightly.
  • Page 8: Install Memory Modules

    Server Deployment Toolkit CD that accompanies your Intel Server System S2400SC, ® ® or go to http://www.intel.com/support/motherboards/server/. Memory sizing and configuration is supported only for qualified DIMMs approved by Intel. For a list of supported memory, see the tested memory list at: http://www.intel.com/support/motherboards/server/.
  • Page 9: Install Hard Drives

    General Installation Process Install Hard Drives Remove the four screws securing the Remove the drive carrier by pressing the plastic drive blank and remove the green button and opening the lever. plastic drive blank. Slide the carrier out. Install the hard disk drive using the same With the lever open, insert the hard disk drive assembly into four screws as shown.
  • Page 10: Install Optical Drive

    General Installation Process Install Optical Drive IMPORTANT NOTE: If you do not Install the plastic guide onto the back Insert the optical drive into chassis opening install a device at this location, of the drive and attach with two screws and push all the way until it stops.
  • Page 11: Install Rack Handles

    Key (optional) NOTE: Rack handles are required to install the bezel. For detailed instructions, see the Service Guide. Locate the white 4-pin key header. Carefully pickup the Intel ® RAID C600 Upgrade Key. Match the Key and connector orientation and press down to install.
  • Page 12: Install Second Power Supply Module (Optional)

    General Installation Process Install Second Power Supply Module (optional) Use the 'finger hole' to remove the Insert the power supply module into the power To remove a power supply module, push the green latch in the direction shown while pulling filler panel.
  • Page 13: Software

    Note: The FRUSDR utility must be run for full server configuration. B. Configure your RAID Controller: If using a RAID card, use the instructions provided with the RAID controller. If using on-board RAID, you must activate RAID in the BIOS setup. See the Intel Server Board ®...
  • Page 14: Reference

    Reference Front Panel Controls and Indicators Standard Control Panel Your system may include one of two front control panel types.The features of each are as follows: A. ID Button with integrated LED F. System Status LED B. NMI Button G. Power Button with integrated LED C.
  • Page 15 Reference Intel® Server Board S2400SC Component Layout ID LED Diagnostic LED Status LED Serial A NIC2 NIC1 USB3 USB1 CPU 2 Power USB2 USB0 SYS FAN_7 CPU 2 Fan Serial B USB 4/5 Front Panel RMM4 NIC RMM4 LITE eUSB SSD...
  • Page 16 Reference System Cabling Diagram R2308SC2SHFN Power Supply (One 600w Fixed) FAN 1 FAN 2 FAN 3 8 x 3.5" HSBP Optical Drive...
  • Page 17 Reference System Cabling Diagram R2308SC2SHDR Power Supply (Two 460w CRPS) FAN 1 FAN 2 FAN 3 8 x 3.5" HSBP Optical Drive...
  • Page 18 Reference System Cabling Diagram R2312SC2SHGR Power Supply (Two 750w CRPS) FAN 1 FAN 2 FAN 3 Interposer Board 12 x 3.5" HSBP...
  • Page 19 (This page is intentionally left blank.)
  • Page 20 G71872-002...
