Intel Product Code
iPC – AXXP3SWX08080
iPC – FXXCPUCLIPF
Intel® Server S2600WF Product Family Configuration Guide and Spares/Accessories List
Order Information
MM# – 958242
UPC – 00735858345637
EAN – 5032037106122
MOQ – 1
MM# – 958275
UPC – 00735858344432
EAN – 5032037105224
MOQ – 2
Product Description
8 Port PCIe x8 Switch AIC
This switch AIC is used to increase the number of PCIe SSD drives
within the system by 8.
The 8 Drive Switch is a full height form factor PCIe card.
Additional Required Accessory:
One of the following cable kits is required to connect the 8 port
switch to the HSBP in R2208, R2208+8 and R2224 systems:
A2U8PSWCXCXK1
A2U8PSWCXCXK2
A2U8PSWCXCXK3
Fabric Processor Clip
This accessory kit provides the clip necessary to attach a Fabric
supported Intel® Xeon® Scalable processor to the CPU Heat Sink.
This kit must be ordered to support dual Fabric CPU configurations
when installing either of the following IFT Carrier Accessory Kits:
AWF1PFABKITM
AWF1PFABKITP
This kit includes (2) Fabric Processor Clips
Product Type
• 2U Accessory Kit
• 1U/2U Accessory / Spare Kit
119
