SmartRunner Matcher*
Vision Configurator Software
Show standard buttons
Show sensor data
Table 5.3
5.3.3

Sensor Menu

Figure 5.5
Load settings
Save settings
Make firmware update
Show device version
Sync with sensor
Table 5.4
Note!
Firmware Update
Once you have upgraded the firmware and Update complete is displayed, restart the sensor.
5.3.4

Image Menu

Figure 5.6
Open image folder
Save image
Copy image to clipboard Loads an image file to the clipboard.
Show graphic
Table 5.5
Toggles the display of the buttons in the bar on the left on and off.
Hides the display of the sensor data in the top right of the screen.
View Menu
Sensor Menu
Loads the saved settings from the sensor
Saves the settings to the sensor
Performs firmware updates. This command should be used by
experienced users only.
Displays the device version
Synchronization with the sensor
Sensor Menu
Image Menu
Opens the folder in which images are currently saved.
Saves the image currently displayed on the PC.
Turns display data sent from the sensor on and off in the image.
Image Menu
25
