SmartRunner Matcher*
Operation
Description of Quality Parameters
1
1
Variation
2
Learned curve
3
Current curve
Quality Variation =
Quality Good =
Quality Outliers =
Legend
X
Number of values in the taught-in profile curve
T
Z
(x) Distance value of the taught-in profile at position x
T
Z
(x) Distance value of the current profile at position x
s
v
Set variation
X
Number of values detected during evaluation, although not present during teach-in
N
X
Number of values that lie outside of the envelope
B
X
Number of values that were present during teach-in, but can no longer be found during
L
evaluation
46
2
3
