SmartRunner Matcher*
Vision Configurator Software
Diagram View - Toolbar
The toolbar is located below the diagram view. There are some useful functions in the toolbar
which are used to further process the diagrams. The following functions are available to you.
1
Position
1
2
3
4
5
2
Designation
Gray scale value
Position details
Show ROIs
Auto reset view
Reset view
3 4
Function
Gray scale value of the pixel
Shows the position of the mouse cursor in the
world coordinate system [mm]
The evaluation range is displayed if the field is
selected.
The evaluation range is hidden if the field is
deactivated.
Automatically jump back to the evaluation
range
Resets to the original view
5
