SmartRunner Detector
Vision Configurator Software
6.1.1

File Menu

Figure 6.2
Change device
Open job
Save job
Quit
Table 6.1
6.1.2

View Menu

Figure 6.3
Show standard buttons
Show sensor data
Table 6.2
6.1.3

Sensor Menu

Figure 6.4
Load settings...
Save settings...
28
File Menu
Disconnects the device and returns to the Login dialog.
Loads a sensor configuration stored on the PC.
Saves the current sensor configuration on the PC.
Terminates the program.
File Menu
View Menu
Toggles the display of the buttons in the bar on the left on and off.
Hides the display of the sensor data in the top right of the screen.
View Menu
Sensor Menu
Loads the saved settings from the sensor
Saves the settings to the sensor
