SmartRunner Matcher*
Vision Configurator Software
Multiprofile menu item
The following description only applies to the "VLM350-F280-R4-1001 and VLM350-F280-R4-
1101". You can save different profiles under the Multiprofile menu item. The stored profiles
can be retrieved at any time. You have the option to create up to 32 different profiles. This
means you are in a position to respond quickly and flexibly in the case of frequent adjustments
to production in particular.
Figure 5.24
The information window consists of 5 columns and 3 buttons. These are explained in more
detail in the following table:
Information window
Designation
Active
State
Number
Name
Information
Multiprofile menu item
Function
The activated profile is marked by a green arrow. A profile is activated
using the Active selected parameter set button. For this purpose,
the desired profile is selected by clicking with the right mouse cursor
and activated using the Active selected parameter set button.
The status light changes from yellow to green as soon as a new profile
is created and confirmed using the Rename/Save selected
parameter set button.
Profile number
The profile name is modified using the Rename/Save selected
parameter set button. Enter the required profile name in the
Parameter set name input field and confirm with OK.
Information about the profile can be entered in the information field.
The information is entered using the Rename/Save selected
parameter set button. Enter the required information in the
Parameter set information input field and confirm with OK .
39
