Chapter 4: BIOS Setup

Advanced

The Advanced menu allows you to configure your system for basic operation.
Some entries are defaults required by the system board, while others, if
enabled, will improve the performance of your system or let you set some
features according to your preference.
Setting incorrect field values may cause the system to
malfunction.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Chipset Security
►
ACPI Settings
► F81216SEC Super IO Configuration
►
NCT7904D HW Monitor
►
Serial Port Console Redirection
► CPU Configuration
PPM Configuration
►
► IDE Configuration
► Miscellaneous Configuration
LPSS & SCC Configuration
►
CSM Configuration
►
► USB Configuration
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
System ACPI Parameters.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
ACPI Settings
This section is used to configure ACPI Settings.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main
Advanced Chipset
ACPI Settings
Enable Hibernation
ACPI Sleep State
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Enable Hibernation
Enables or disables system ability to hibernate (OS/S4 Sleep State). This
option may not be effective with some OS.
ACPI Sleep State
Select the highest ACPI sleep state the system will enter when the suspend
button is pressed. The options are Suspend Disabled and S3 (Suspend to
RAM).
30
Exit
PCIPnP Security
Enables or Disables System
ability to Hibernate (OS/S4 Sleep
State). This option may be not
[Enabled]
effective with some OS.
[S3 (Suspend to RAM)]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
