Chapter 1: Product Introduction
Knowing Your NIFE 103
Front View
COM
Port
USB 2.0
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
LED Indicators
Indicates the power, battery, WLAN, WWAN and GPO activity of
COM Port
DB9 port used to connect RS232/485 compatible devices.
LED
Indicators
LAN1 and LAN2 Ports
Two LAN ports used to connect the system to a local area network.
USB 2.0 and USB 3.0 Ports
USB 2.0 and USB 3.0 ports to connect the system with USB devices.
LAN1
LAN2
USB 3.0
4
the system.
NIFE 103 User Manual
