Chapter 3: System Setup
Installing a Wi-Fi Module
1. Locate the half-size mini-PCIe slot on the board for the Wi-Fi module.
Insert the Wi-Fi module into the slot at 45 degree angle until the gold-
plated connector on the edge of the module completely disappears into
the slot.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
2. Push the module down and secure it with a screw. Ensure the screw is
fixed tightly to the slot.
Half-size
mini-PCIe
slot
23
NIFE 103 User Manual
