Chapter 4: BIOS Setup
Data Bits
The options are 7 and 8.
Parity
A parity bit can be sent with the data bits to detect some transmission errors.
Even Parity bit is 0 if the number of 1's in the data bits is even.
Odd Parity bit is 0 if number of 1's in the data bits is odd.
Stop Bits
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning). The standard setting is 1 stop bit. Communication with slow
devices may require more than 1 stop bit.
Flow Control
Flow control can prevent data loss from buffer overflow. When sending data
and the receiving buffers are full, a "stop" signal can be sent to stop the
data flow.
VT-UTF8 Combo Key Support
Enables or disables VT-UTF8 combo key support.
Recorder Mode
When this field is enabled, only text will be sent. This is to capture the
terminal data.
Resolution 100x31
Enables or disables extended terminal resolution.
Legacy OS Redirection
Selects the number of rows and columns that support redirection.
Putty KeyPad
Selects the Putty keyboard emulation type.
Redirection After BIOS POST
Enables or disables redirection after BIOS POST.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
CPU Configuration
This section is used to configure the CPU.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
CPU Configuration
 Socket 0 CPU Information
CPU Speed
64-bit
Active Processor Core
Limit CPUID Maximum
Execute Disable Bit
Intel Virtualization
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Active Processor Core
Select the number of cores to enable in each processor package.
Limit CPUID Maximum
The CPUID instruction of some newer CPUs will return a value greater
than 3. The default is Disabled because this problem does not exist in the
Windows series operating systems. If you are using an operating system
other than Windows, this problem may occur. To avoid this problem, enable
this field to limit the return value to 3 or lesser than 3.
34
Socket specific CPU Information
1467 MHz
Supported
[All]
[Disabled]
[Enabled]
[Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
