Chapter 4: BIOS Setup
Serial Port Console Redirection
This section is used to configure the serial port that will be used for console
redirection.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
COM0
Console Redirection [Enabled]
►
Console Redirection Settings
Serial Port for Out-of-Band Management /
Windows Emergency Management Services (EMS)
Console Redirection [Disabled]
►
Console Redirection Settings
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Console Redirection
Enables or disables the console redirection.
Console Redirection (Serial Port for Out-of-Band Management)
Enables or disables the console redirection. When enabled, Console
Redirection Settings will be available.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
COM0 Console Redirection Settings
Console Redirection Enable or
Disable.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Terminal Type
ANSI
VT100
VT100+ Extends VT100 to support color, function keys, etc.
VT-UTF8 Uses UTF8 encoding to map Unicode characters onto 1 or more
Bits Per Second
Selects the serial port transmission speed. The speed must match the other
side. Long or noisy lines may require a lower speed.
33
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
COM0
Console Redirection Settings
Terminal Type [ANSI]
Bits per second [115200]
Data Bits [8]
Parity [None]
Stop Bits [1]
Flow Control [None]
VT-UTF8 Combo Key Sup [Enabled]
Recorder Mode [Disabled]
Resolution 100x31 [Disabled]
Legacy OS Redirection [80x24]
[VT100]
Putty KeyPad
Redirection After BIO [Always Enable]
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Extended ASCII character set.
ASCII character set.
bytes.
Emulation: ANSI: Extended
ASCII char set. VT100: ASCII
char set. VT100+: Extends
VT100 to support color, function
keys, etc.
VT-UTF8: Uses UTF8 encoding
to map Unicode chars onto 1
or more
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
