4.3

Accessory/Option Specifications

Control Software

Compatible operating system
Functions
Main unit settings
Captured data
Display
Display modes
File conversion
Monitor functions
Report function
Maximum/Minimum

Accessories

Quick Start Guide
CD-ROM
AC adapter

Battery Pack B-517 (Option)

Capacity
Running time
Battery type
Charging method
Time required for charging
Switchover in the case of a
power failure
Operation environment
Other functions
Item
Windows XP/Vista/Windows 7
Main unit control, realtime data capture, data conversion, data replay
AMP settings, Data Capture settings,Trigger Alarm settings, Report settings,
Other settings
Realtime data (CSV, Binary)
Internal memory (CSV, Binary)
USB memory (CSV, Binary)
Analog waveforms, logic waveforms, pulse waveforms, digital values
Y-T View, Digital View, Report View, X-Y View between Cursors (only during
replay)
Between cursors, All data, Thinning function
Alarm monitor enables sending of email to the specified address
Automatic creation of daily or monthly files
The maximum, minimum and current values are displayed during measurement
Item
GL220-UM-8 xx
GL220-CDM 0 x M (User's Manual, Application software)
100 to 240 VAC, 50/60 Hz, one set of region-specific power cables
Item
7.4V/2200mAh 17Wh
When using the LCD display: approx. 5 hours
When using the screensaver: approx. 6 hours
Note: When capturing to internal memory at 1 s, sampling, using new battery
packs at +25°C environment.
Note: The running time depends on such as the operating environment, the
amount of charge left in the battery and connecting USB memory.
Lithium secondary battery
Mount in the main unit, or use a separate battery charger
Main unit: approx. 4 hours
Because the battery is used together with the AC adapter, the power supply
will be switched automatically to the battery in the event of a power failure.
Note: The AC adapter is the primary power source.
Running on battery: 0 to 40°C, Battery being charged: 15 to 35°C
When the battery is running low, measured data is saved and the file is clised
automatically (during internal memory and USB memory capture).
The remaining battery power is displayed.
Description
Remarks
Description
CHAPTER 4 Specifications
Quantity
1
1
1
4-7
