(8) Text input
Related to text input operations such as annotation, EU (scaling) unit and captured data file name input.
• Operation
Operation mode
Text input A
a
0
+
← Delete mode
↓
OK Finalize mode
When selecting Text used for each operation
operation
Description
Upper case alphabet mode
Lower case alphabet mode
Numeric mode
Symbol mode
Insert mode
CHAPTER 3 Settings and Measurement
Operation method
When the cursor key is moved to
the uppermost part, operation can
be selected using the left/right key.
After selecting an operation, use the
down key to move the cursor to the
desired character.
When you bring the cursor to a
character and press ENTER, the
character is entered. After you finish
entering characters, move the cur-
sor to OK and then press ENTER.
3−43
