CHAPTER 2 Checks and Preparation
2.1
Checking the Outer Casing
After unpacking, check the GL220's outer casing before use. In particular, please check for the following:
●
Surface scratches
●
Other flaws such as stains or dirt
2.2
Checking the Accessories
After unpacking, check that the following standard accessories are included.
Standard Accessories
Quick Start Guide
CD-ROM
AC cable/AC adapter
Optional Accessories
Logic alarm cable
DC drive cable
Battery pack
Humidity sensor *1
Humidity sensor power box
M3 screws with flat washers (60)
USB memory 2GB
Shunt resistor 250 Ω
T-type thermocouple *2
K-type thermocouple *2
Extra fine K-type thermocouple
(TC200/TD1000), 5 per set
Needle-shape K-type
thermocouple
Stationery-surface K-type
thermocouple
L-type stationery-surface K-type
thermocouple
Mini-connector for K-type
thermocouple (5 per set)
Mini-connector for K-type
thermocouple (2 per set)
Mini-connector for T-type
thermocouple (5 per set)
Mini-connector for T-type
thermocouple (2 per set)
*1: Allowable temperature range: -25 to +80°C
*2: Sold only in Japan.
2-2
Item
GL220-UM-85x
User's Manual, Application software
100 to 240 VAC, 50/60 Hz
Item
Option number
B-513
B-514
B-517
B-530
B-542
B-543
B-550
B-551
JBS-7115-5M-T
JBS-7115-5M-K
ST-55K-TC-1.2M
RIC-410
RIC-420
RIC-430
RIC-440
RIC-441
RIC-450
RIC-451
Remarks
Remarks
2m, Bare tips
2m, Bare tips
7.4V/2200mAh 17Wh
3 m, with dedicated power connector
For connection with 10 humidity sensors: Built to order
60 per set
2GB
250 Ω, Rated power of 1 W, Maximum service voltage of
15.8 V, Built to order
5-m length, 5 thermocouples per set, wire diameter of
0.32, 1.0 x 1.6 x 5000 mm
5-m length, 5 thermocouples per set, wire diameter of
0.32, 1.0 x 1.6 x 5000 mm
Tip wire diameter of 0.127, 0.5 x 0.7 x 200 mm, Relay
part 1 m, 5 per set
-100 to 300°C, Class 1, Cord length: 1.1 m
-30 to 400°C, Class 2, Cord length: 1.1 m
-30 to 600°C, Class 2, Cord length: 1.1 m
5 per set, Connectable thermocouple: Wire diameter of
0.65 mm, End terminal: M3Y terminal
2 per set, Connectable thermocouple: Wire diameter of
0.65 mm, End terminal: M3Y terminal
5 per set, Connectable thermocouple: Wire diameter of
0.65 mm, End terminal: M3Y terminal
2 per set, Connectable thermocouple: Wire diameter of
0.65 mm, End terminal: M3Y terminal
Quantity
1
1
1
