Internal memory devices

Memory capacity
Memory contents

PC Interface

Interface types
Functions
USB functions
Realtime data transfer speed

Monitor

Display
Displayed languages
Backlight life
Backlight
Item
Internal memory : Approx. 2GB Flash Memory
USB memory
• Setup conditions
• Measured data
• Screen copy
Item
USB (Full speed)
• Data transfer to the PC (realtime, memory)
• PC control of the GL220
USB drive mode:Transfers and deletes file from internal memory
10 ms/1ch maximum
Item
4.3-inch TFT color LCD (WQVGA: 480 x 272 dots)
English, French, Japanese, German, Chinese, Korean
20000 hr (when brightness is down to 50%), depends on operation environment
Screen saver function provided (10, 30 s, 1, 2, 5, 10, 30, 60 min.)
Description
: Unlimited (However, one file must be 2GB at the maximum.)
Description
Description
CHAPTER 4 Specifications
4-3
