(7) File box
The file box used to set captured data files using the DATA menu or for disk operations accessed using the
FILE menu is operated as follows.
<File box by disk operations>
Key
Change the operation of the file box.
Show properties ........................ Display details of a file or folder.
Select file/folder ......................... Select files or folders to write data.
Create new folder ...................... Create a new folder.
Create new file .......................... Create a new file.
Rename ..................................... Change the file or folder name.
Copy file/folder ........................... Copy files or folders.
Select file to copy/delete ........... Select the file to copy or delete.
Select copy destination and copy ... Select the copy destination and copy.
Delete file/folder ........................ Delete files or folders.
Change file sort order ................ Change the order in which files are displayed.
View setting ............................... Change displaying information for files.
Format disk ................................ Format the disk.
* Details of allowed operation will depend on the operation target.
Moves between folders.
: Move up one folder.
: Move down one folder.
ENTER
Finalize the operation.
QUIT Close the file box.
<Setting example>
The following shows an operation example where a folder named "TEST" is created for captured data and
automatically saved.
Description
In the [Data save Destination], choose [Select folder] and
press the ENTER key.
