CHAPTER 3 Settings and Measurement
(6)-6 Save
Saves the setting conditions of the GL220.
<If the naming method is Auto>
(1) Folder
(2) File
(3) Name Type
(6)-7 Load
Loads and reflects the GL220 setting conditions from a file.
(1) File
3−40
Setting
Specify a folder to which you want to save data. Refer to page 3-41, "File box" for details.
Specify a file to which you want to save data. Refer to page 3-41, "File box" for details.
Set how a data file should be named.
Auto
Arbitrary
Sequential number
Setting
Specify a file to which you want to save data. Refer to page 3-41, "File box" for details.
<If the naming method is Arbitrary>
Description
: Automatically supplies the file name.
Example: 20050101-123456_UG.CND
Number part : File creation date
* The file is created on January 1, 2005, 12:34:56 in this
example.
UG : User number of the user capturing data
UG: Guest
U1: User 1
U2: User 2
CND : Data format
(GL220 setting file format)
: Data is captured to a file with an entered file name.
: A file is created with an arbitrary file name that has been entered, followed by
a sequential number.
Description
